SPECIFICATION

1,Working Medium:Air source

2,Body material:Aluminum die-casting

3,Filter bowl material:PC

4,Filter element material:Brass or Plastic

5,Seal Material:NBR

6,Working pressure:0.05~0.63MPa

7,Working Temperature:5~60℃

8,Filtration fineness:50µ

9,Mounting type: Pipe-line mounting

10,Regulator type:Diaphragm type

11,Port size:G1/4”,G3/8”,G1/2”,G3/4”,G1”,G1-1/4”,G1-1/2”,G2”
